fischer Brass Dowel MS 4 x 15, 026424

Der fischer Messingdübel MS ist ein Spreizdübel aus Messing für die Aufnahme eines metrischen Gewindes. Der Spezialdübel wird in der Vorsteckmontage gesetzt. Beim Eindrehen der Schraube oder der Gewin

more details
Meesenburg Article Number:
Manufacturer item no.: 026424
EAN: 4006209264249
Verkaufseinheit

Product advantages

The compact design of the brass anchor reduces the drilling effort and ensures a quick installation.
The special surface structure of the MS prevents it from rotating in the borehole. This increases the assembly security.
The internal thread allows the use of standard metric screws or threaded rods and enables flush disassembly and reusability of the fixing point. This achieves a high level of flexibility.
Product properties
Product properties

Description

Der fischer Messingdübel MS ist ein Spreizdübel aus Messing für die Aufnahme eines metrischen Gewindes. Der Spezialdübel wird in der Vorsteckmontage gesetzt. Beim Eindrehen der Schraube oder der Gewindestange spreizt der Messingdübel auf und verankert sich gegen die Bohrlochwand. Der fischer Messingdübel MS ist vor allem geeignet für die Befestigung von Regalen, Durchlauferhitzern und Aggregaten in Vollbaustoffen.
Product properties
Anchorage base
Weight
133 g
Min. drill hole depth
20 mm
Brand
fischerwerke_gmbh_co_kg
technical data
Drilling diameter: 5 [mm] Dowel length: 15 [mm] Design: without screw Packaging variant: folding box Thread: M4 Min. drilling depth: 20 [mm] Min. screw-in depth: 15 [mm]
